Rockwell Automation Publication 2097-UM002D-EN-P - April 2017 113
Troubleshoot the Kinetix 350 Drive Chapter 7
Error Codes
The following list helps you resolve memory anomalies.
When a fault is detected, the status indicator displays an E and a two-digit
error code until the anomaly is cleared.
Fault Codes
These fault code tables are designed to help you resolve anomalies. When a
fault is detected, the four-digit status indicator scrolls the display message. The
display is repeated until the fault code is cleared.
Table 44 - Fault Code Summary
Error
Code
Anomaly Possible Cause Action/Solution
E38 Memory module error. Bad memory module. Replace memory module.
E76 Blank memory module. A Blank MEM module has been
inserted into the drive.
Push and hold the drive's enter key
(bottom most red button) on the drive's
front display until the drive shows bUSY.
This makes the drive format the blank
memory module for usage with the drive.
Fault Code Type Description
S xx
Conditions that prevent the drive from enabling, see Table 45.
Scxx
F xx
Standard axis fault, see Table 46
and Table 4 7.
Fcxx
Lxxx
Unrecoverable errors that occur during the boot process.
Return drive to Rockwell Automation.
Pxxx
Unrecoverable errors that occurred during the Power on Self Test (POST). Return drive
to Rockwell Automation.
Icxx Anomalies that prevent normal operation and occur during the initialization process.
nFxx
Anomalies that prevent normal operation of the drive. Node Fault. This type of fault
that impacts the servo drive not just the axis of motion.
Table 45 - S xx and Scxx Start Inhibit Codes
Four-digit Display
RSLogix 5000® and Logix
Designer Fault Message
Problem or Symptom Potential Cause Possible Resolution
S 01 Axis enable input.
The axis enable input is
deactivated.
Axis Enable Input is not active.
• Check wiring and 24V source for drive
ENABLE Input.
• Disable enableInputChecking
attribute by using a message
instruction.
