Rockwell Automation Publication 2097-UM002D-EN-P - April 2017 29
Install the Kinetix 350 Drive System Chapter 2
Cable Categories for Kinetix 350 Drive Components
This table indicates the zoning requirements of cables that are connected to the
Kinetix 350 drive components.
Table 11 - Kinetix 350 Drive Components
Noise Reduction Guidelines for Drive Accessories
See this section when mounting an AC line filter or shunt resistor module for
guidelines that are designed to reduce system failures that excessive electrical
noises cause.
AC Line Filters
If you are using a Bulletin 2090 line filter, mount the filter on the same panel as
the Kinetix 350 drive, and as close to the drive as possible.
Observe these guidelines when mounting your AC line filter:
• Good HF bonding to the panel is critical. For painted panels, refer to
the examples on page 24
.
• Segregate input and output wiring as far as possible.
Wire/Cable Connector
Zone Method
Very
Dirty
Dirty Clean
Ferrite
Sleeve
Shielded
Cable
L1, L2, L3 (unshielded cable) IPD X
U, V, W (motor power) MP X X
B+-, B-, BR (shunt resistor) BC X
24V DC BP X
Control COM, 24V DC control, safety enable, and
feedback signals for safe-off feature
STO X
Motor feedback MF X X
Registration
IOD
XX
Others X
Ethernet Port 1 X X
