Allen-Bradley Kinetix 350 User Manual

72 Rockwell Automation Publication 2097-UM002D-EN-P - April 2017
Chapter 4 Connect the Kinetix 350 Drive System
Wiring the Feedback and I/O
Connectors
These procedures assume that you have mounted your Kinetix 350 system,
completed the power wiring, and are ready to connect motor feedback.
Wire the I/O Connector
Connect your I/O wires to the IOD connector by using the 2097-TB1 I/O
Terminal Expansion Block. See the Kinetix 300 I/O Terminal Expansion
Block Installation Instructions, publication 2097-IN005
.
Figure 40 - Kinetix 350 Drive (IOD Connector and Terminal Block)
)
1
11
12
20
21
29
30
40
50
GND
I/O (IOD)
Connector
2097-TB1
I/O Terminal
Expansion Block
