Appendix B Upgrade the Kinetix 350 Drive Firmware
Configure Logix5000
Communication
This procedure assumes that your are communicating to the Logix5000
controller by using the Ethernet protocol. It is also assumed that your Logix5000
Ethernet module has already been configured.
For more information, see the ControlLogix® System User Manual, publication
1756-UM001
.
Follow these steps to configure Logix5000 communication.
1. Open your RSLinx® Classic software.
2. From the Communications pull-down menu, choose Configure Drivers.
The Configure Drivers dialog box appears.
3. From the Available Drive Types pull-down menu, choose Ethernet devices.
4. Click Add New.
The Add New RSLinx Classic Driver dialog box appears.
5. Type the new driver name.
