Chapter 3 Kinetix 350 Drive Connector Data
AC Input Power Connector Pinout
Back-up Power Connector Pinout
Shunt Resistor and DC Bus Connector Pinout
Motor Power Connector Pinout
IPD
Designator
Description
(2097-V31PRx-LM drives)
Signal
IPD
Designator
Description
(2097-V32PRx-LM drives)
Signal
L2/N AC power in (non-doubler operation) L2/N L2 AC power in L2
L1 AC power in L1 L1 AC power in L1
N AC power neutral (only 120V doubler) N PE Protective earth (ground) PE
PE Protective earth (ground) PE
IPD
Designator
Description
(2097-V33PRx-LM, and 2097-
V34PRx-LM drives)
Signal
L3 AC power in (three-phase models) L3
L2 AC power in L2
L1 AC power in L1
PE Protective earth (ground) PE
BP
Designator
Description Signal
+24V Positive 24V DC +24V DC
-24V 24V DC power supply return Return
BC
Designator
Description Signal
+
Positive DC bus and shunt resistor
+
++
SH Shunt resistor SH
-
Negative DC bus
-
--
MP
Designator
Description Signal
PE Protective earth (ground) PE
W Motor power out W
V Motor power out V
U Motor power out U
