22 Rockwell Automation Publication 2097-UM002D-EN-P - April 2017
Chapter 2 Install the Kinetix 350 Drive System
In this example, the enclosure must have an exterior surface of at least 4.53 m.
If any portion of the enclosure is not able to transfer heat, exclude heat in the
calculation.
Because the minimum cabinet depth to house the Kinetix 350 system (selected
for this example) is 332 mm (13 in.), the cabinet must be approximately 2000 x
700 x 332 mm (78.7 x 27.6 x 13.0 in.) HxWxD.
2 x (0.332 x 0.70) + 2 x (0.332 x 2.0) + 2 x (0.70 x 2.0) = 4.59 m²
Because this cabinet size is considerably larger than what is necessary to house
the system components, it can be more efficient to provide a means of cooling
in a smaller cabinet. Contact your cabinet manufacturer for options available to
cool your cabinet.
Power Dissipation Specifications
This table shows the maximum power dissipation of each drive. Use this table
to size an enclosure and calculate required ventilation for your Kinetix 350
drive system.
Cat. No. Power Dissipation, W
2097-V31PR0-LM 28
2097-V31PR2-LM 39
2097-V32PR0-LM 28
2097-V32PR2-LM 39
2097-V32PR4-LM 67
2097-V33PR1-LM 28
2097-V33PR3-LM 39
2097-V33PR5-LM 67
2097-V33PR6-LM 117
2097-V34PR3-LM 39
2097-V34PR5-LM 58
2097-V34PR6-LM 99
