Rockwell Automation Publication 2097-UM002D-EN-P - April 2017 149
Upgrade the Kinetix 350 Drive Firmware Appendix B
10. The Update Status dialog box appears and indicates success or failure as
described here.
11. Click OK.
Verify the Firmware Upgrade
Follow these steps to verify that your firmware upgrade was successful.
Open your RSLinx software.
12. From the Communications pull-down menu, choose RSWho.
13. Expand your Ethernet node, Logix5000 backplane, and EtherNet/IP
network module.
14. Right-click the drive module and choose Device Properties.
Upgrading Status If
Success 1. Update complete appears in a GREEN Status dialog box.
2. Go to step 11.
Failure 1. Update failure appears in a RED Status dialog box.
2. See ControlFLASH Firmware Upgrade Kit Quick Start, publication 1756-
QS105, for troubleshooting information.
Verifying that the firmware upgrade is optional.
