20 Rockwell Automation Publication 2097-UM002D-EN-P - April 2017
Chapter 2 Install the Kinetix 350 Drive System
Contactor Ratings
Table 8 - Kinetix 350 Drives (120/240V)
Table 9 - Kinetix 350 Drives (240V)
Table 10 - Kinetix 350 Drives (480V)
Transformer Selection
The Kinetix 350 drive does not require an isolation transformer for three-
phase input power. However, a transformer can be required to match the
voltage requirements of the controller to the available service.
To choose the size of a transformer for the main AC power inputs, refer to on
page 18
and Transformer Specifications for Input Power on page 21.
Cat. No.
Drive
Voltage
AC Coil Contactor DC Coil Contactor
2097-V31PR0-LM
120V 100-C23x10 100-C23Zx10
240V 100-C12x10 100-C12Zx10
2097-V31PR2-LM
120V 100-C30x10 100-C30Zx10
240V 100-C23x10 100-C23Zx10
Cat. No.
Drive
Voltage
AC Coil Contactor DC Coil Contactor
2097-V32PR0-LM 240V 100-C23x10 100-C23Zx10
2097-V32PR2-LM 240V 100-C23x10 100-C23Zx10
2097-V32PR4-LM 240V 100-C30x10 100-C30Zx10
2097-V33PR1-LM
120V 100-C23x10 100-C23Zx10
240V 100-C16x10 100-C16Zx10
2097-V33PR3-LM
120V 100-C23x10 100-C23Zx10
240V 100-C16x10 100-C16Zx10
2097-V33PR5-LM
120V 100-C30x10 100-C30Zx10
240V 100-C23x10 100-C23Zx10
2097-V33PR6-LM
120V N/A N/A
240V 100-C30x10 100-C30Zx10
Cat. No.
Drive
Voltage
AC Coil Contactor DC Coil Contactor
2097-V34PR3-LM
480V
100-C12x10 100-C12Zx10
2097-V34PR5-LM 100-C12x10 100-C12Zx10
2097-V34PR6-LM 100-C23x10 100-C23Zx10
IMPORTANT If you are using an autotransformer, make sure that the phase to neutral/
ground voltages do not exceed the input voltage ratings of the drive.
