140 Rockwell Automation Publication 2097-UM002D-EN-P - April 2017
Appendix A Interconnect Diagrams
Motor Brake Currents
Use these coil current values to size the interposing relay that is required for
your application. See the interconnect diagram for your Kinetix 350 drive/
motor beginning on page 134
for typical motor brake circuitry. See Kinetix
Rotary Motion Specifications Technical Data, publication KNX-TD001
for
more information on Motor Holding brake specifications.
Table 62 - Motor Brake Coil Currents
Compatible Brake Motors/Actuators
(1)
(1) Use of the variable x indicates that this specification applies to 230V and 460V motors.
Coil Current
MPL-x1510, MPL-x1520, MPL-x1530 0.43…0.53 A
MPL-x210, MPL-x220, MPL-x230 0.46…0.56 A
MPL/MPF-x310, MPL/MPF-x320, MPL/MPF-x330
0.45…0.55 AMPM-x115
MPS-x330
MPL-x420, MPL-x430, MPL-x4520, MPL-x4530, MPL-x4540,
MPL-B4560
0.576…0.704 A
MPM-x130
MPF-x430, MPF-x4530, MPF-x4540
MPS-x4540
TLY-A110T, TLY-A120T, and TLY-A130T 0.18…0.22 A
TLY-A220T and TLY-A230T 0.333…0.407 A
TLY-A2530P, TLY-A2540P, and TLY-A310M 0.351…0.429 A
