APRILIA RX 125 Service Station Manual

•
Apply SILASTIC 732 RTV to the cable
guide of coil and stator, then slide it in
the crankcase hollow space.
•
Fit the electric starter device cover on
the starter gear.
Stator installation
•
Insert the woodruff key in the crank-
shaft.
•
Place the stator.
•
Tighten the three stator fixing screws.
Flywheel cover installation
•
Apply a thin layer of SILASTIC 732
RTV on the flywheel cover centring.
•
Place the flywheel cover.
Engine RX SX 125
ENG - 100

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
