APRILIA RX 125 Service Station Manual

Installing
SHOCK ABSORBER FITTING
•
Fit the shock absorber by inserting
from the bottom.
•
Insert the shock absorber upper screw
with the washer from the left side.
•
Working from the opposite side, tighten
the nut (1).
•
Position the connecting rod assembly
on the shock absorber.
•
Insert the shock absorber lower screw
from the right side.
•
Working from the opposite side, tighten
the nut (2).
•
Place the double connecting rod in its
seat on the chassis.
•
From the left side insert the nut fixing
the connecting rod assembly plus the
washer in the chassis.
•
Working from the opposite side, tighten
the nut (3).
•
Remove the support between the
swingarm and the saddle post frame.
Linkages
RX SX 125 Suspensions
SUSP - 169

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
