APRILIA RX 125 Service Station Manual

•
Undo and remove both screws that fix
the silencer support bracket to the
chassis and collect the washer.
•
Slide off the silencer backwards.
See also
Side body panels
Removing the exhaust manifold
•
Undo and remove the screw that fixes
the muffler to the chassis and collect
the washer.
•
Release the two cylinder attachment
springs.
•
Release the secondary air pipe sealing
clamp and slide off the pipe.
RX SX 125 Chassis
CHAS - 185

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
