Seat
Place the vehicle on the service stand.
Insert the key in the lock.
Turn the key anticlockwise.
Lift and remove the saddle.
UPON REFITTING:
BEFORE LOWERING AND LOCKING THE SADDLE,
CHECK THAT THE KEY HAS NOT BEEN LEFT INSIDE THE
GLOVE-BOX / TOOLKIT COMPARTMENT.
Fit the saddle making sure to position
the corresponding rear hooks correct-
ly.
Lower and press the saddle to trip the
lock.
BEFORE RIDING, MAKE SURE THAT THE SADDLE IS
CORRECTLY LOCKED INTO POSITION.
Headlight assy.
Undo and remove both screws on the
upper plate.
Undo and remove the two screws fas-
tening the mudguard and collect the
nuts and washers from the bottom.
Bodywork RX SX 125
BODYW - 200

Table of Contents

Other manuals for APRILIA RX 125

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the APRILIA RX 125 and is the answer not in the manual?

APRILIA RX 125 Specifications

General IconGeneral
Displacement124.2 cc
Max Power11 kW (15 HP) @ 10, 700 rpm
Torque11.2 Nm @ 8, 000 rpm
Fuel SystemElectronic fuel injection
Transmission6-speed
Rear SuspensionMonoshock
Front BrakeSingle disc, 300 mm
Rear BrakeSingle disc, 220 mm
Seat Height905 mm
Weight134 kg (dry)
Engine TypeSingle cylinder, 4-stroke
Cooling SystemLiquid-cooled
Front SuspensionUpside-down fork
ABSYes
