APRILIA RX 125 Service Station Manual

3. Dust guard
4. Dust guard support ring
5. Roller bearing
6. Sealing ring
7. TE screw
8. Washer
9. Fork upper plate
10.Fork lower ring nut
11.Base with headstock
12.TCE screw
13.Screw
14.U-bolt
Adjusting play
•
Unscrew and remove the four screws
and collect the washers.
•
Remove both U-bolts.
•
Undo and remove both upper plate
screws.
•
Tap the bottom side to push upwards the upper plate together with handlebar and ignition
switch / steering lock.
•
Move the upper plate forwards, place a piece of cloth to avoid damaging the instrument
panel.
Suspensions RX SX 125
SUSP - 160

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
