APRILIA RX 125 Service Station Manual

2. Silencer
3. Silencer clamp
4. Muffler protection
5. Silent-block
6. M6 Flanged self-locking nut
7. Insulating washer
8. Clip M6
9. TE flanged screw M6x16
10.Traction cyl. helical spring
11.TCEI M6x16 screw
12.Silencer plate
13.M6x12 TE flanged screw
14.6.4X11X0.5 spring washer
15.6.6x18x1.6 washer
16.Insulating washer
17.Central exhaust pipe
18.Silencer gasket
19.Lower self locking nut
20.Pull screw
21.Plate
22.Washer
Removing the tail pipe
•
Rotating it on the screw, move the fair-
ing that covers the chassis.
•
Undo and remove the front fixing screw
of the silencer pipe and collect the
washer.
Chassis RX SX 125
CHAS - 184

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
