APRILIA RX 125 Service Station Manual

Front mudguard
•
Undo and remove the two screws and
collect the washers.
•
Undo and remove the two upper
screws and collect the nuts (1) and
washers.
•
Unscrew and remove the four screws
(2) and collect the washers.
•
Slide off the front mudguard forwards,
paying attention to the front fitting slots.
Mixture oil tank
•
Remove saddle, central right and left
fairings and right chassis cover.
•
Remove the clamp.
Bodywork RX SX 125
BODYW - 210

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
