Battery

BATTERY

(12 V - B9 - B)

(12 V - 4 A)

In case of malfunction check first that the recharge system works properly. To check the battery, remove

it from the vehicle, and proceed as follows; visually check that :

- there are no signs of sulphation (signalled by white colouring of one or more cells);

- the electrolyte level is between the two "MIN" and "MAX" reference notches;

- the container (outer casing) does not leak.

Charge the battery slowly for at least 10 hours. With a densimeter check the electrolyte density at every

cell after recharging. If the density is below 1.26 at any cell or if the off-load voltage is lower than 12V,

the battery surely needs to be replaced.

Speed sensor

Operating voltage: Vdc= 5÷24 V

Maximum voltage applicable: 26 V

Maximum reverse voltage: -16 V

Maximum power consumption: 10 mA

Operating temperature:

-20 °C ÷ +80 °C (-7.6 °F ÷ -112 °F)

Electrical system RX SX 125

ELE SYS - 64
