APRILIA RX 125 Service Station Manual

•
Remove the water pump with the help
of a square screwdriver.
REFITTING
•
Upon refitting follow the removal steps but in reverse order, paying special attention to the
alignment of the water pump control wheel, which must be aligned with the reference on the
crankcase when refitting.
Removing the radiator
•
Remove both front side fairings.
•
Place a container of suitable capacity
underneath the sleeve.
•
Release the clamp.
•
Slide off the sleeve.
•
Empty the liquid into the container.
•
Open the radiator cap to facilitate
drainage.
Cooling system RX SX 125
COOL SYS - 196

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
