APRILIA RX 125 Service Station Manual

•
Top-up the reservoir you are working with (1 or 2) until the level goes over the minimum
marked MIN.
CAUTION
TOP-UP TO MAXIMUM LEVEL MARK ONLY WHEN BRAKE PADS ARE NEW. BRAKE FLUID LEV-
EL DECREASES GRADUALLY AS BRAKE PADS WEAR OUT.
WHEN TOPPING-UP, DO NOT EXCEED THE MAXIMUM LEVEL MARK WHEN BRAKE PADS ARE
WORN AS YOU RISK SPILLING FLUID WHEN CHANGING THE BRAKE PADS.
•
Check braking efficiency.
•
In case of excessive travel of the brake lever or poor performance of the braking system,
purge the air in the system.
Clutch system
Adjusting the lever
Adjustment clutch when the engine stops or the
vehicle tends to move forward even when clutch
lever is operated and the gear engaged, or if the
clutch "slides", resulting in acceleration delay con-
sidering the engine revs.
Minor adjustments can be carried out through the
set screw (1) ):
•
Remove the protection casing (2).
•
Loosen the nut (3) (screw in).
•
Turn the set screw (1) until the empty
travel at the clutch lever end is approx-
imately 10 - 15 mm (0.39 - 0.59 in) (see
figure).
RX SX 125 Maintenance
MAIN - 31

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
