APRILIA RX 125 Service Station Manual

•
Operating from both sides, undo and
remove the chassis fixing screw and
collect the nut.
CAUTION
ONCE THE CHASSIS IS RELEASED PAY ATTENTION TO
THE REAR SIDE OF THE MOTORCYCLE AND PLACE IT ON
THE GROUND LOWERING THE HOIST.
•
Slide the filter casing upwards.
Fuel tank
TANK COVER
•
Remove the saddle.
•
Undo and remove the two screws.
•
Undo and remove the front screw.
•
Disconnect the fuel vapour recovery
pipe.
•
Unscrew and remove the fuel tank cap.
•
Remove the fuel tank cover and screw the cap again.
See also
Bodywork RX SX 125
BODYW - 208
