Undo and remove the upper screw (2)
and collect the nut (6).
Undo and remove the screw (3) and
collect the rubber ring (5).
Remove the upper chain guide slider
(4).
Undo and remove the two lower
screws (2).
Remove the lower chain guide slider
(1).
Exhaust
KEY
1. Muffler
RX SX 125 Chassis
CHAS - 183
