Circuit diagram
Key:
1. Fuel tank
2. Fuel cock
3. Oil mixer tank
4. Oil reservoir cap
5. Oil level gauge
Carburettor
Removing
Remove the fuel tank.
Undo the two screws.
Power supply RX SX 125
P SUPP - 130
