APRILIA RX 125 Service Station Manual

•
Place the connecting rod assembly on
the swingarm.
•
Insert the screw from the right side.
•
Fit the washer and tighten the nut (9).
•
Position the brake hoses on the swing-
arm.
•
Fasten the internal brake pipe clamp
with the screw (10).
•
Fasten the brake hose guide with the
screw (11).
•
Mount the rear wheel.
•
Assemble the chain.
•
Lower the hoist arm.
•
Release the belts from the chassis.
•
Install the fuel tank.
•
Place the speed sensor.
Drive chain
RX SX 125 Chassis
CHAS - 179

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
