APRILIA RX 125 Service Station Manual

•
Undo and remove the fixing screw.
The following operations refer to only one fair-
ing, but are valid for both.
•
Undo and remove the radiator fixing
screw.
•
Remove the front side fairing.
CHASSIS COVER
•
They are placed in the central area on
both sides of the vehicle. For regular
operations remove the three clamps
and turn the cover according to visibil-
ity requirements, acting on the lower
screw slightly loose.
If necessary, remove them from the vehicle:
•
Remove the three retaining clamps.
Bodywork RX SX 125
BODYW - 204

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
