APRILIA RX 125 Service Station Manual

Checking the clutch hub
•
When the clutch hub is worn, this may
cause bell sliding problems. Replace
the hub if its surface has exceeded the
wear limit. Max. wear limit (A) 0.3 mm
(0.012 in).
Assembling the clutch
•
Check that the needle bearings are in-
stalled on the secondary shaft.
•
Install the clutch base.
•
Fit the disc pack pre-assembled on the
clutch base which has been previously
placed on the secondary shaft.
Head and timing
Engine RX SX 125
ENG - 104

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
