APRILIA RX 125 Service Station Manual

•
Place a stand under the tyre to keep
the wheel in position once it is free.
•
Slide off the wheel pin from the left
side.
•
Collect the spacer from the left side.
•
Remove the wheel by sliding it off from the front.
Checking the front wheel
CAUTION
CHECK THAT ALL THE PARTS ARE IN GOOD CONDITIONS, ESPECIALLY THOSE MENTIONED
BELOW.
BEARINGS
Turn the internal ring manually; it must rotate
smoothly, continuously and silently.
There must be no axial clearance.
The bearings presenting these problems must be
replaced.
GASKETS
Check that the gaskets are in good conditions; replace them if they show signs of damage or excessive
wear.
Suspensions RX SX 125
SUSP - 142

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
