Engine parameter screen page
ENGINE PARAMETER READING
Specification Desc./Quantity
Engine revs rpm, measured with crankshaft rpm detection sensor
Throttle valve opening %, indication ranges from 0 to 100 %
Air temperature 23 °C, if signal is lost, the control unit set the value to 50 °C
Battery voltage 12 V
Ignition advance 12 °, ignition advance with respect to TDC
Warm - up time (from KEY ON) s
Vehicle speed 0 km / h
Devices activation screen page
DEVICE ACTIVATION
Specification Desc./Quantity
Deleting errors By pressing the 'enter' button, the stored errors (MEM) become
part of the historical data (STO). The next time Axone is con-
nected to the ECU, the errors in the historical record (STO) will
no longer be displayed
Coil The coil is activated five times
Outlet valve The solenoid valve is activated five times
Intake air solenoid valve The solenoid valve is activated five times
Rpm indicator The needle should be at 10000 rpm for two seconds
Speed gauge Activates the speedometer at 100 km / h
Errors display screen page
CAUTION
IF THERE IS ANY ENGINE FAILURE, THE CONTROL UNIT DOES NOT TURN ON THE EFI WARN-
ING LIGHT.
THE EFI WARNING LIGHT IS INACTIVE IN THIS VEHICLE.
THE OPERATOR WHO ENCOUNTERS A FAILURE IN THE ENGINE MUST CARRY OUT ALL THE
PRESCRIBED AXONE CHECKS WITH THE AIM OF ENSURING THE ENGINE HAS BEEN THOR-
OUGHLY CHECKED.
ERRORS DISPLAY
Specification
Desc./Quantity
EEPROM : checksum error. Signal not valid Control unit internal error
Data zone EEPROM not valid : default values reset Control unit internal error
Crankshaft position sensor Circuit open An interruption has been detected between pin 9 and pin 3 of
the small connector in the control unit
Crankshaft position sensor Shorted to ground Continuity has been detected between the ground connection
and pin 9
Crankshaft position sensor Signal not valid Abnormal voltage has been detected due to an electric resist-
ance not foreseen in the circuit connecting to the revolution
sensor: between pin 9 and pin 3 of the small connector of the
control unit
Ignition capacitor Shorted to ground Error detected in the capacitor charging system in the control
unit: check that the power supply and ground connection of the
control unit are adequate
Ignition coil (circuit open) Lack of ground connection to pin 14 has been detected
No ignition Error detected in the capacitor charging system in the control
unit: check that the power supply and ground connection of the
control unit are adequate
No ignition Error detected in the capacitor charging system in the control
unit: check that the power supply and ground connection of the
control unit are adequate
Incorrect crankshaft signal. Signal not valid Abnormal error detected by the control unit
RX SX 125 Power supply
P SUPP - 137
