APRILIA RX 125 Service Station Manual

Installing the fork legs
•
Insert the sleeve together with the
wheel holder stem on the lower and
upper plates.
•
Insert the wheel pin through both
stems to align the holes.
•
Tighten the screw that locks the lower
plate to the sleeve.
•
Tighten the screw that blocks the upper
plate to the sleeve.
Suspensions RX SX 125
SUSP - 158

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
