11.Seeger ring
12.Oil seal
13.Rear wheel pin
14.Low self-locking nut
15.Washer
16.Rear wheel spacer
17.Crown
18.Low self-locking nut
19.Curved spring washer
20.TSPEI screw
21.Chain with master link
22.Bare rear wheel
23.Bearings spacer
24.Hub bearing
Removing the rear wheel
Rest the vehicle on the specific OP-
TIONAL stands.
Unscrew and remove the nut and re-
trieve the washer.
RX SX 125 Suspensions
SUSP - 163
