APRILIA RX 125 Service Station Manual

•
Tighten the six flywheel cover fixing
screws.
Clutch side
Removing the clutch cover
•
Undo and remove the nine screws fix-
ing the clutch cover.
•
Lift the clutch cover using two screw-
drivers as levers at the prearranged
points paying special attention not to
damage the seal surfaces and the gas-
ket.
•
Remove the gasket.
RX SX 125 Engine
ENG - 101

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
