APRILIA RX 125 Service Station Manual

Removing
•
Place the engine support so as to fa-
cilitate oil pump removal operations.
•
Undo and remove the two screws fixing
the oil pump.
•
Remove the oil pump and the O-ring
underneath; collect the oil pipes and
their guides.
Inspection
•
Male sure the delivery (1) and intake
(2) pipes do not leak or have pores at
their connecting points. Replace if re-
quired.
•
Clean the oil reservoir, the oil reservoir
filter and the oil intake pipe.
•
Always replace the oil pump when
damaged or leaking.
•
After installing the flexible pipe of the
oil pump, adjust it so that when in idle
position the marks on the pump lever
(3) are aligned with the pump (4) seat.
BLEEDING
Purge the oil pump and its pipes:
Engine RX SX 125
ENG - 126

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
