APRILIA RX 125 Service Station Manual

TURN INDICATORS
•
If necessary, remove the turn indica-
tors working from any side, then undo
and remove the screw and carefully
slide off the gauge with cables.
LICENSE PLATE LIGHT
•
If necessary, remove the license plate
light, undo and take out the screw and
carefully slide off the light with cables.
REAR LIGHT
•
If necessary remove the rear light, un-
do and take out both screws and collect
the washers.
•
Slide off the rear light with cables care-
fully.
Side body panels
CENTRAL FAIRING
The following operations refer to only one fair-
ing but are valid for both.
•
Unscrew and remove the screw and
collect the collar.
Bodywork RX SX 125
BODYW - 202

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
