APRILIA RX 125 Service Station Manual

•
Tighten the bleed screw again and fill
the reservoir until the oil reaches the
recommended level.
Battery
BATTERY REMOVAL
•
Remove the saddle.
•
Make sure the ignition switch is set to
«OFF».
•
Disconnect the negative ( -) lead first
and then the positive (red) (+) one.
•
Remove the battery breather pipe.
•
Remove the battery from its housing
and put it away on a level surface in a
cool and dry place.
CAUTION
ONCE REMOVED, THE BATTERY MUST BE PUT AWAY IN
A SAFE PLACE OUT OF THE REACH OF CHILDREN.
Tail guard
•
Remove the saddle and the central
side fairings.
•
Undo and remove the two screws.
•
Undo and remove the two lower
screws.
Bodywork RX SX 125
BODYW - 212

APRILIA RX 125 Specifications

General

Displacement	124.2 cc
Max Power	11 kW (15 HP) @ 10, 700 rpm
Torque	11.2 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Brake	Single disc, 300 mm
Rear Brake	Single disc, 220 mm
Seat Height	905 mm
Weight	134 kg (dry)
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Suspension	Upside-down fork
ABS	Yes
