3.5.3 No paper fed manual feed slot (Error code 9A)
Not detect paper at feeding from manual feed slot
3.5.4 Double feeding
User Check
• Load the paper into the manual feed slot.
Step Cause Remedy
1
Harness connection failure of
registration front/rear sensor PCB
ASSY
Check the harness connection of the
registration front/rear sensor PCB ASSY,
and reconnect it.
2
Low voltage power supply PCB
ASSY failure
Replace the low voltage power supply PCB
ASSY.
3 Main PCB failure Replace the main PCB ASSY.
4
Registration front/rear sensor
failure
Check the sensor performance following
the procedure in "Operational check of
sensors" (Chapter 5).
If any problem occurs, replace the regist
frame ASSY.
User Check
• Check if the paper is loaded into the paper tray correctly.
• Check if the thickness of the paper is 60 to 105 g/m
2
.
• Clean the separation pad.
• Check that too much paper is not loaded in each tray.
Step Cause Remedy
1 Paper feeding roller failure Replace the paper feeding kit.

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
