Brother MFC-7365DN Service Manual

1-1
Confidential
1. SPECIFICATIONS LIST
1.1 General
Specifications are subject to change without notice.
Model
DCP-7055
DCP-7057
DCP-7057E
DCP-7055W
DCP-7057W
DCP-7060D DCP-7065DN
DCP-7070DW
HL-2280DW
Print method Electrophotographic / Laser
Resolution 600 dpi x 600 dpi, HQ1200 (2400 X 600 dpi) quality
Print speed Up to 20/21 ppm Up to 24/24
ppm
Up to 26/27 ppm
* When loading A4 or Letter-size paper from the paper tray.
Warm-up time From Sleep Mode: Less than 7 seconds
* At 23°C (73.4F)
From Power OFF → ON: Less than 27 seconds From Power
OFF → ON:
Less than
28 seconds
* At 23°C (73.4F)
First print
time
From Ready
mode
Less than 10.0 seconds Less than 8.5 seconds
From Sleep
mode
Less than 19.0 seconds Less than 16.5 seconds
CPU ARM9 200MHz
Memory 16 MB 32 MB
Backup Clock
N/A
Interface Hi-Speed
USB 2.0
Hi-Speed USB
2.0,
IEEE802.11b/g
(Infrastructure
Mode / Adhoc
Mode)
Hi-Speed
USB 2.0
Hi-Speed
USB 2.0,
Ethernet 10/
100 BASE-
TX
Hi-Speed USB
2.0, Ethernet
10/100 BASE-
TX,
IEEE802.11b/g
(Infrastructure
Mode / Adhoc
Mode)
Power
Consumption
* Measured
with only
USB
connected
Peak 1080 W
Copying Average: Approximately 445 W
Ready Average: Approximately 55 W
Sleep,
Wireless
LAN: ON
N/A Average:
Approximately
2.8 W
N/A Average:
Approximately
2.8 W
Deep Sleep Average:
Approximately
0.9 W
Average:
Approximately
1.0 W
Average: Approximately
0.9 W
Average:
Approximately
1.0 W

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
