Brother MFC-7365DN Service Manual

2-101
Confidential
3.12.4 A communication error occurs
3.12.5 Reception mode cannot be changed
3.12.6 Caller ID are not displayed
3.12.7 Cannot talk on the handset
Step Cause Remedy
1 NCU PCB failure Replace the NCU PCB ASSY.
2 Main PCB failure Replace the main PCB ASSY.
User Check
• Turn OFF the Distinctive ring mode.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
User Check
• Verify that the handset curled cord is securely inserted into the socket.
• Adjust the handset volume.
Step Cause Remedy
1 Handset curled cord failure Replace the handset curled cord.
2 Handset ASSY failure Replace the handset ASSY.
3 Hook switch PCB ASSY failure Replace the hook switch PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
