Brother MFC-7365DN Service Manual

3-4
Confidential
4. SCREW TORQUE LIST
Note:
• For verifying the shape of each screw, refer to "3. SCREW CATALOGUE" in this chapter.
Location of screw Screw type Q’ty
Tightening torque
N · m (kgf · cm)
Tray cover Taptite bind B M4x12 2 0.8±0.1 (8±1)
Cord hook Taptite cup B M3x8 2 0.4±0.05 (4±0.5)
Inner chute ASSY Taptite bind B M4x12 2 0.8±0.1 (8±1)
Side cover L Taptite bind B M4x12 3 0.8±0.1 (8±1)
Upper/Lower handset cover Taptite pan B M3x8 1 0.5±0.1 (5±1)
Side cover R Taptite bind B M4x12 1 0.8±0.1 (8±1)
ADF FG Harness / FB FG harness Taptite cup S M3x6 SR 1 0.8±0.1 (8±1)
Hinge ASSY L
Taptite bind B M4x12 1 0.8±0.1 (8±1)
Taptite cup S M3x12 3 0.8±0.1 (8±1)
Hinge arm R Taptite cup B M3x10 4 0.5±0.1 (5±1)
Upper Document Chute ASSY Taptite cup B M3x10 6 0.5±0.1 (5±1)
Lower Document Chute ASSY Taptite cup B M3x10 3 0.5±0.1 (5±1)
ADF sensor harness unit Taptite cup S M3x6 SR 1 0.8±0.1 (8±1)
Drive frame ASSY Taptite cup B M3x10 3 0.5±0.1 (5±1)
ADF motor
Screw pan (S/P washer)
M3x6
10.35±0.05 (3.5±0.5)
Panel unit Taptite cup B M3x10 4 0.5±0.1 (5±1)
Document scanner top cover Taptite bind B M4x12 6 0.8±0.1 (8±1)
Speaker cover Taptite bind B M4x12 1 0.8±0.1 (8±1)
NCU FG harness ASSY (upper side)
Screw pan (S/P washer)
M3.5x6
1
0.8±0.1 (8±1)
VIETNAM
*1
1
0.6±0.05 (6±0.5)
CHINA
*1
NCU FG harness ASSY (right side) 10.5±0.05 (5±0.5)
NCU unit Taptite bind B M4x12 2 0.8±0.1 (8±1)
NCU ASSY Taptite cup S M3x6 SR 2 0.5±0.1 (5±1)
Joint Cover Taptite bind B M4x12 4 0.8±0.1 (8±1)
Fuser unit Taptite pan B M4x14 2 0.8±0.1 (8±1)
LV shield plate cover
Taptite bind B M4x12 3 0.8±0.1 (8±1)
Screw pan (S/P washer)
M3.5x6
10.5±0.05 (5±0.5)
Screw pan (S/P washer)
M3x12DB
10.5±0.1 (5±1)

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
