Brother MFC-7365DN Service Manual

2-22
Confidential
3.3 Communications Error Code
*1 Available in German models only.
Code 1 Code 2 Cause
Refer to:
10 08 Wrong number called. 2-101
11 01 No dial tone detected before start of dialing. 2-101
11 02 Busy tone detected before dialing. 2-101
11 03 2nd dial tone not detected. 2-101
11 05 No loop current detected.
*1
2-101
11 06 Busy tone detected after dialing or called. 2-101
11 07 No response from the remote station in sending. 2-101
11 10 Unobtainable tone detected after dialing. 2-101
17 07 No response from the calling station in receiving. 2-101
20 01 Unable to detect a flag field. 2-101
20 02 Carrier was OFF for 200 ms or longer. 2-101
20 03 Abort detected (“1” in succession for 7 bits or more). 2-101
20 04 Overrun detected. 2-101
20 05 A frame for 3 seconds or more received. 2-101
20 06 CRC error in answerback. 2-101
20 07 Echo command received. 2-101
20 08 Invalid command received. 2-101
20 09
Command ignored once for document setting or for dumping-
out at turn-around transmission.
2-101
20 0A T5 time-out error 2-101
20 0B CRP received. 2-101
20 0C EOR and NULL received. 2-101
32 01
Remote terminal only with V.29 capability in 2,400 or 4,800 bps
transmission.
2-101
32 02 Remote terminal not ready for polling. 2-101
32 10
Remote terminal not equipped with password function or its
password switch OFF.
2-101
32 11
Remote terminal not equipped with or not ready for
confidential mailbox function.
2-101
32 12
Remote terminal not equipped with or not ready for relay
function.
2-101
32 13 No confidential mail in the remote terminal. 2-101

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
