Brother MFC-7365DN Service Manual

5-4
Confidential
1.4.2 Printout of scanning compensation data (Function code 05)
<Function>
The machine prints out the brightness level data for scanning compensation.
<Operating Procedure>
(1) For white and black scanning, copy the document. For color scanning, implement color
scanning of the document.
(2) Press the 0 and 5 buttons in this order in the initial state of the maintenance mode. In the
case of the model without the numeric keys; Press the or button. The
“MAINTENANCE 05” appears on the LCD. Then press the OK button. The “PRINTING”
will appear on the LCD, and the equipment prints out the scanning compensation data
list (Refer to Fig. 5-1) containing the following:
■ Black and white/color scanning
Note:
• Be sure to execute this operating procedure not immediately after the power is turned
ON, but after conducting the document scanning operation at least once in scanning.
Since the machine initializes the brightness level data and obtains the standard value
for document scanning compensation when starting scanning the document, the
correct data for compensation cannot be printed out even if this operation is
implemented without scanning the document.
• The print result varies depending on whether implementing color scanning or black and
white scanning immediately before this operating procedure. Make sure the brightness
level data you want to print and implement the operation below.
Note:
• In the case of the black and white scanning, the output data (B) and (R) are invalid.
a) LED CURRENT DATA 1 Byte
b) LED pulse data 1(UP) (G) 2 Bytes
c) LED pulse data 1(DOWN) (G) 2 Bytes
d) LED pulse data 1(UP) (B) 2 Bytes
e) LED pulse data 1(DOWN) (B) 2 Bytes
f) LED pulse data 1(UP) (R) 2 Bytes
g) LED pulse data 1(DOWN) (R) 2 Bytes
h) REFH data 1 Bytes
i) Background color compensated data 1 Byte
j) Black level data by previous scanning pixel count
k) White level data (G) by previous scanning pixel count
l) White level data (B) by previous scanning pixel count
m) White level data (R) by previous scanning pixel count

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
