Brother MFC-7365DN Service Manual

App. 2-1
Confidential
APPENDIX 2 DELETION OF USER SETTING INFORMATION, ETC.
In this machine, the user setting information is stored in the EEPROM and flash memory of
the main PCB. You can delete all the data listed below at a time with the procedure given
below.
• Information related to Net
• User setting information
(1) Press the Menu button while the machine is in the ready state.
(2) Press the or button, then the “Initial Setup” or “General Setup” will appear on the
LCD and press the OK button.
(Which will appear, “Initial Setup” or “General Setup”, depends on the model.)
(3) Press the or button, then the “Reset Menu” will appear on the LCD and press the
OK button.
(4) Press the or button, then the “All Settings” will appear on the LCD and press the
OK button.
(5) The “1.Reset/2.Exit” will appear on the LCD.
(6) Press the 1 button, and the user setting information is deleted, and the machine goes
back to the ready state.
Note:
• The machine returns to the ready state automatically if no panel operation is
implemented for 30 seconds.

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
