Perform a Paper Path Registration
Introduction
NOTE
Only trained operators who have permission to perform POC actions, and Service Technicians,
are allowed to perform the paper path registration.
The paper path registration adjusts the registration for bulk media for printer-dependent offsets.
Usually, the paper path registration is performed by a Service Technician at the installation or
after a software upgradeThe paper path registration adjustment is a machine adjustment. The
paper path registration is the basis of the media registration. The media-specific adjustment
creates a difference with the bulk registration adjustment.
When to do
The Service Technician must perform the paper path registration adjustment after the
replacement or disassembly of certain units.
After the trained operator replaced the heat exchanger foils, the trained operator must verify the
media registration. If the media registration is not optimal, the paper path registration adjustment
is required.
NOTE
After the bulk registration adjustment, the media-specific registration can be changed. It is
recommended to verify the media registration for the specific media. If the media registration is
not satisfactory, the media specific registration is required.
Procedure
1.
On the control panel, touch [System] -> [Maintenance] -> [Go to maintenance tasks] -> Printer
registration adjustment A4/Letter -> [Start].
The tray for the A4/LTR bulk media is tray 1.
NOTE
You must first perform the paper path registration adjustment for A4/LTR and after that
you must perform the paper path registration adjustment for A3/Ledger.
NOTE
When the optional bulk tray for small format is installed, make sure that bulk tray 1
contains A4 or Letter. Also, make sure that you have assigned A4 or Letter to bulk tray
1. If needed you must adjust the size of the tray (see
Adjust the Size of the optional
Bulk Tray for small Format
on page 301).
2.
Enter the maintenance PIN
WARNING
Only trained personnel is allowed to carry out POC actions.
3.
Follow the instructions on the screen.
If the printer has not warmed up, the registration starts with warming up the printer.
Perform a Paper Path Registration
Chapter 14 - Maintain the print system
371
