5C0 – 22ICLUTCH
DAEWOO V–121 BL4
3. Remove the pushrod assembly and the piston as-
sembly.
4. Inspect the cup and the piston for wear. Fluid leaks
will show wear on the cup and the piston. Replace
the cup and the piston if necessary.
5. Remove the pushrod assembly and the piston as-
sembly.
6. Inspect the pushrod for wear. Repair the pushrod if
necessary.
Assembly Procedure
1. Apply clean fluid to the piston assembly cup and
insert the piston assembly and the pushrod assem-
bly into the master cylinder body.
2. Install the piston stop ring using ring pliers. Install
the boot.
3. Install the clutch master cylinder assembly into the
vehicle. Refer to ”Clutch Master Cylinder Assembl”
in this section.
