9U – 14ICRUISE CONRTOL SYSTEM
DAEWOO V–121 BL4
4. Install the mounting bracket.
Tighten
Tighten the actuator bracket nuts to 18 NSm (13 lb–ft).
5. If the adjuster spring is not fully compressed, press
the cable release button and slide the cable into the
adjuster until the spring is fully compressed.
Notice : When the adjuster button is pressed, do not allow
the adjuster spring to expand to a length of more than 2 cm
(3/4 inch) or the adjuster rack will come out of the adjuster,
and will have to be re–inserted. To keep the adjuster in one
piece during adjustment, hold the cable when the adjuster
button is pressed.
6. Insert the cable adjuster into the adjuster bracket.
7. Press the cable release button and adjust the cable
to achieve a gap of 0.5 mm (0.02 inches) between
the bushing and the nipple of the cable ball.
8. Install the knee bolster. Refer to Section 9G, Interi-
or Trim.
9. Install the knee bolster trim panel.
