Configuring VRRP 1221

Default VRRP Values

Table 37-1 shows the global default values for VRRP.

Table 37-1. VRRP Defaults

Parameter Default Value

Admin Mode Disabled

Virtual Router ID (VRID) None (Range 1-255)

Preempt Mode Enabled

Preempt Delay 0 Seconds

Learn Advertisement Timer Interval Enabled

Accept Mode Disabled

Priority 100

Advertisement Interval 1

Authentication None

Route Tracking No routes tracked

Interface Tracking No interfaces tracked
