AH Motion Controller – Operation Manual
3-2
Before developing an AH Motion system, you need to install ISPSoft and COMMGR, which are basic software. ISPSoft is
a platform for integrating the program development of a whole system, hardware configuration, and network configuration.
COMMGR functions as middleware between a computer and devices. For example, it functions as a communication
management interface between ISPSoft and AH Motion system hardware.
3.1 Installing and Uninstalling ISPSoft
System Requirements
Windows 2000/NT/Me/XP/Vista/7/8/10
256 MB or above (A memory having a capacity of 512 MB or above is recommended.)
Capacity : 500 MB or above
CD-ROM drive
For installing ISPSoft
It is optionally required.
Monitor
Resolution: 800×600 or above
(Setting which is suggested: 1024x768/96 dpi)
A general keyboard/mouse, or devices compatible with Windows
Printer
A printer with a driver for Windows
(It is used to print a project, and is optionally required.)
One of them is used, but a PLC which is connected
must have a corresponding port. (*1)
Communication
COMMGR, a communication manager, must be installed on a computer. (*2)
Models which are
supported
AH500 series PLCs (including AH Motion CPUs)/DVP series PLCs (exclusive of DVP-PM
series PLCs)/VFD-C2000 series AC motor drives/VFD-C200 series AC motor
drives/VFD-CP2000 AC motor drives /VFD-E AC motor drives (*3)
*Note:
1. ISPSoft supports several ways in which a computer is connected to a PLC. You have to make sure of the port and the
mode supported by a PLC before a computer is connected to the PLC.
*2. Please refer to section 3.2 for more information about COMMGR.
*3. In addition to ISPSoft, you must use PMSoft version 2.05 or above to develop AH10PM-5A and AH20MC-5A.
*4. The functions and specifications mentioned above are only applicable to ISPSoft version 2.00 or above. The older
versions are not equipped with the complete functions.
