Eaton EASY-E4 Series User Manual

6. Function blocks
6.3 UF - User function block
Marker contents
If this option is enabled, the contents of the existing retentive market range will be
retained when the project is transferred. In order for this to work, however, the marker
range defined as being retentive must remain unchanged .
Function block contents
If this option is enabled, the contents of the existing retentive operand range will be
retained when the project is transferred. In order for this to work, however, the function
block defined as being retentive must remain unchanged .
The marker actual values are retained when you have selected the option Retain Mark-
ers During Transfer.
Comment section
This box can be used to enter an optional comment, e.g., in order to distinguish between
various versions of a user function block.
6.3.4 Programming a user function block
Once you have created a user function block, the view will automatically switch to the
Programming view for the user function block. Moreover, a tab with the user function
block's name and version will appear next to the Main program tab in the work pane.
User function blocks are programmed exactly the same way as a main program. The
only difference is that there are slightly fewer operands available (the list of available
operands and function blocks will automatically change to reflect this).
You should be in the Programming view for the user function block. Following is a
screenshot showing an example in which a timing relay is programmed with the flash-
ing operating mode.
easyE4 11/18 MN050009 EN www.eaton.com
439
