4. Operation
4.1 Base device with display and buttons
4.1.4 Cursor display
The cursor buttons in the easyE4 program perform three functions:
l Move
l Enter
l Connect
The current mode is indicated by the appearance of the flashing cursor.
Current selection flashes on the easyE4 display
œ
In Move mode, use to position the cursor on the circuit diagram
in order to select a rung, a contact or a relay coil or
the selection position of a coil function or a NET-ID.
I 01
Use the OK button to switch to Entry mode so that you can enter or change a value
at the current cursor position.
Press the ESC button in Entry mode
to restore to the last changes of an entry.
l
Press the ALT button to switch to Connect mode for wiring contacts and relays.
Press the ALT button again to return to Move.
ESC Press the ESC button to leave the program (circuit diagram and parameter display).
4.1.5 Entering of values
Used to select a position.
Use to select values
and/or a setting
ESC Cancel, retain previous value
OK Store settings
90
easyE4 11/18 MN050009 EN www.eaton.com
