7. System settings
7.8 Setting the startup behavior
The RUN START option will be enabled by default on the EASY-E4-..., as
well as after a factory reset.
What will happen if the program is deleted
The startup mode setting is a device function and will be retained even if the circuit dia-
gram is deleted.
Upload/download to memory card or PLC
The setting will be retained when a valid program is transferred.
7.8.2 Enabling / disabling the CARD START option
The mode for starting up with a memory card is intended for applications in which it is
necessary for it to be possible to change programs easily and quickly by changing the
memory card.
If the program on the memory card is different to the program in the easyE4 device, the
program from the card will be loaded on power up first of all and then started in RUN
mode. If the programs only contain different function block SETPOINT values (con-
stants), the program on the memory card is not loaded.
The program is retained in the device and is started. If there is no circuit diagram on the
memory card the device will remain in STOP mode.
Default setting CARD START inactive
7.8.2.1 Configuration on a base device with a display
In order to be able to configure this option, the program must be in STOP mode. If it is
not, the device will point this out.
Go to the main menu.
Go to SYSTEM OPTIONS\SYSTEM.
Select the CARD START menu option.
Press the OK button to enable and disable the option.
If there is a checkmark ü next to the menu option, the program will be loaded from the
memory card and applied as soon as the easyE4 device is switched on.
If there is no check mark, the current program will be kept.
7.8.2.2 Configuring the easySoft 7
You can enable and disable this option in easySoft 7.
Select the device you want from the catalog in the Project view
Click on the System settings tab.
Go to the Memory card / device ID section and find the checkbox for Card start.
To turn on, enable the checkbox by clicking on it.
To turn off, disable the checkbox by clicking on it.
easyE4 11/18 MN050009 EN www.eaton.com
467
