Electrolux 30" User Manual

132
Insulation
2. Remove the four screws, two on each side, holding
the shield to the inner liner.
Two screws
Removing large oven bake element:
1. Disconnect power and remove the two screws that
hold the element to the oven liner.
2. Pull the element into the oven and disconnect the
wires.
Two screws
Removing the broil element large oven:
1. Disconnect power and unsnap the two wire hanger
from the front of the element.
Two wire hanger
2. Remove the two screws holding broil element to the
liner and pull the element into the oven.
Two screws
Removing the oven sensor in the large oven:
1. Disconnect power, remove the shield from the rear
of the range and unplug the sensor.
Disconnect the sensor
2. Remove the two screws holding the sensor to the
rear wall and pull the sensor into the oven.
