Removing the large door righthand hinge roller
bracket:
1. Disconnect power, remove the righthand bodyside
and heat shield.
2. Remove the two screws holding the bracket to the
front frame and slide the roller bracket out the back.
Two screws
Roller bracket
Removing the large door lefthand hinge roller
bracket:
1. Remove the two screws holding the bracket to
the front frame and slide the roller bracket down.
Two screws
2. Raise the corner of the small bottom heat shield
and pull the roller bracket down between the small
shield and the large shield.
Push up
